The Pinnacle of Optics: Fused silica Applications and Innovations

Table of Content [Hide]

    Fused silica, a specialty industrial glass composed solely of silicon dioxide (SiO2), stands as a cornerstone material in modern technology due to its exceptional physical and chemical properties. Renowned as the "King of Glass" by experts in the field, Fused silica is indispensable in strategic sectors such as information technology, optics, photovoltaics, semiconductors.

    Structural Characteristics and Unique Properties

    Composition and Bonding

    Fused silica is uniquely composed of pure silicon dioxide, with its Si-O bonds exhibiting a short-range order and long-range disorder structure. Given the high bond energy and stability of Si-O bonds, Fused silica boasts several remarkable properties:

    Property

    Description

    High Softening Temperature

    Maintains structural integrity under extreme thermal conditions (withstands temperatures up to 1580°C)

    Broad Spectral Transmission

    Exceptional transparency across wide spectrum: 160nm (far UV) to 5μm (far IR), surpassing conventional optical glass performance

    Low Thermal Expansion & Conductivity

    Thermal expansion coefficient of 0.55×10-6/K and electrical resistivity >1016Ω·cm ensures dimensional stability

    Chemical & Radiation Resistance

    Maintains 99.6% original transmittance after 108rad gamma exposure, resistant to acids (except HF) and alkalis


    These properties make Fused silica a preferred material for critical applications in optics, space exploration, and advanced technology.


    Fused Silica Applications in Advanced Technologies

    Application Field

    Material

    Key Properties

    Application Examples

    Optical Fibers & Telecommunications

    Fused Silica

    High resistance to interference
    Rapid transmission speed (up to 100+ Gbps)
    Large bandwidth capacity

    Fiber-optic communication systems
    Space exploration instruments
    Inertial navigation systems

    Optical Components (New Energy)

    High-purity Silica

    UV-transparent (180-2500nm wavelength)
    Thermal stability
    Radiation resistance

    "Shen Guang-III" laser components:
    - Vacuum windows
    - Beam sampling gratings
    - Continuous phase plates

    Micro-Optics

    Fused Quartz

    Broad spectral transmission (UV to IR)
    Low thermal expansion (0.55×10⁻⁶/°C)
    Surface roughness < 5Å

    Smartphone cameras
    Medical endoscopes
    CCD/CMOS sensors
    Augmented reality displays



    Implications and Research Needs

    Fused silica's significance in semiconductor, and precision instrument industries is profound, directly influencing the resolution, accuracy, stability, and reliability of related equipment. Despite its excellent radiation resistance, prolonged exposure to high-energy charged particles in space can degrade Fused silica's optical and other properties, impacting component longevity.

    Therefore, investigating the effects of space ionizing radiation on Fused silica materials is crucial. Such research can inform strategies to mitigate radiation-induced degradation, ensuring the continued reliability and performance of Fused silica in space applications.
